840-1000 Roof Panel Forming Machine
High-efficiency metal roofing panel roll former with dual profile output (840/1000mm), 8-10m/min speed and +/-1mm cutting precision.
840-1000 Roof Panel Forming Machine
The 840-1000 roof panel forming machine is a professional-grade roll forming equipment designed to produce high-quality metal roof panels with various profiles and appearances. It handles color-coated steel, galvanized sheets and aluminum-zinc alloy with excellent consistency for industrial and residential construction markets.
Protection For Long Term, Lasting Health
High Efficiency
13 forming stations with stable output.
Precision Engineering
70mm quenched shafts, chrome-plated rollers.
PLC Control
Automatic length and quantity management.
Multi Material
Color steel, galvanized, Al-Zn alloy.
Our Application
Industrial Buildings
Factories, warehouses, workshops.
Commercial Projects
Malls, stadiums, exhibition halls.
Residential Roofing
Apartments, villas and community housing.
Technical Specifications
| Machine Type | Roof Panel Roll Forming Machine |
| Panel Width | 840mm / 1000mm |
| Material Thickness | 0.2 - 0.8mm |
| Forming Stations | 13 rows |
| Forming Speed | 8 - 10 m/min |
| Dimensions | 6400 x 1300 x 950 mm |
| Shaft Diameter | 70mm (45# steel) |
| Main Motor | 3kW |
| Hydraulic Pump | 3kW |
| Uncoiler | Manual (Hydraulic optional) |
| Load Capacity | 5 Tons |
| Shearing Method | Hydraulic |
| Tolerance | +/-1mm |
Standard Configuration
- Manual Uncoiler — 1 Set
- Forming Main Unit — 1 Set
- Hydraulic Shearing System — 1 Set
- PLC Control Cabinet — 1 Set
- Hydraulic Oil Pump Station — 1 Set
- Discharge Rack — 1 Set
Optional Upgrades
- Hydraulic Uncoiler
- Automatic Shearing Machine
- Custom Profile Dies
- Additional Language Support
Our Certificate
CE
ISO
Quality Test
Patent
Factory Story
Strict Roller Calibration
Each forming station is tested and calibrated before shipment to ensure profile consistency.
Hydraulic System Validation
Hydraulic pressure and shearing performance are verified under continuous load test.
FAQ
What materials can this machine process?
Color-coated steel, galvanized steel, aluminum-zinc alloy, and zinc-aluminum-magnesium with 0.2-0.8mm thickness.
What is daily production capacity?
At 8-10m/min, it can produce about 3,840-4,800 meters in an 8-hour shift.
What warranty is provided?
12-month warranty for mechanical/electrical parts, plus lifetime technical support.
